FMK motorized s.r.o.

GARAGE DOOR OPENER

DOORMAX

Doormax ceiling drive with LED light is a simple and reliable drive type for a residential door. The drive programming is very simple and intuitive. It is provided with the soft start and stop function with a reliable obstacle detection. Electrical protection of the entrance door or a battery providing the power supply in case of the power outage can also be installed.

DOORMAX

PARAMETER

Model	600N/600N-Speed	1000N/1000N-Speed	1200N
Input voltage	220-240V / 110-127V, 50-60Hz
Max. opening speed	160mm/second 200mm/second
Max. door height	2400-5000mm
Bottom base material	Metal
Drive mechanism	Chain/Belt
Frequency	433.92MHz / 868MHz
Max. door area	7m²	11m²	13m²
Max. door weight	90kg	140kg	160kg

TECHNOLOGY & STANDARDS

All of our door motors garage are CE, RCM & TUV certified for the entire European & Australian market.Our products are EN12453 & EN12445 approved and include all of the options to make your products smart and compatible in home automation.

Soft-Start & Soft-Soft
Terminal devices supported
Reversal height setting(force margin)
Transformer overload protection
Travel speed setting(door dependent)
Partial open/height setting
L.E.D off delay time setting (1min*N N=1--9)
Automatic closing time setting (time & height)

	Single C rail with chain/belt	C rail cut in 3 pieces with chain/belt
Length	For doors up to	For doors up to
3150mm	2300mm	2300mm
3500mm	2700mm	2700mm
3800mm	3000mm	3000mm
4000mm	3200mm	3200mm

AUTO CLOSE

FMK garage door openers have an auto close function. The close time can be adjustable from 15s to 135s.
HIGH BRIGHTNESS LED

A whole surface translucent white LED light cover design. High line LED bright the garage, energy conservation and smart setting for courtesy lighting control.
POSTMAN FUNCTION

With F-LinX you’ll always know what’s going on at home, even while you’re away. Let in the postman. It’s peace of mind right in the palm of your hand.You can enjoy your holiday with peace of mind.
Control & Settings

F-linX is a powerful APP platform which is based on residential, commercial and industrial door and gate openers. It contains almost all the basic functions like open / stop / close the door or gates, partial open, LED light controlling, auto close and force margin and so on. All of them can be set through our F-linX APP.
