Light Industrial door
Commecial Door
Residential Garage Door
Standard lifting
Size, Weight & Height:
- Up to 18 m2
- Up to 234 Kgs
- Up to 5.0m
High Lifting
Size, Weight & Height:
- Up to 18 m2
- Up to 234 Kgs
- Up to 5.0m
Vertical lifting
Size, Weight & Height :
- Up to 14 m2
- Up to 182 Kgs
- Up to 5.0m
BASE35
x 1
Control box
x 1
Connecting cable controller to motor
x 1
Power cable
x 1
Release cord
x 1
Bracket
x 1
| Maximum output torque | 35Nm |
|---|---|
| Rated output torque | 25Nm |
| Input voltage | 110/220(1+10%)V 50Hz |
| Control system | 24V DC |
| Motor power | 0.35KW |
| Static holding torque | 400Nm |
| Max. output speed | 24rpm - 32rpm |
| Operation limit turns (limit travel) | 15 turns of output shaft (max. 5.0m lifting height recommend) |
| Sleeve shaft diameter (standard) | φ25.4mm |
| Keyway size | 6.3mm |
| Thermal protection temperature | 105℃ |
| Continuous sound pressure level | ＜70dB |
| Max. cycles per hour | 20 |
| IP protection class | IP54 |
| Temperature range | - 20℃ ~ + 60℃ |
| Standard kit | Drive motor & push button or TX/RX control |
| Quick release with rope | Including |
| Chain hoist module | None |
Optional edge sensors kit | Optional |
Power cable extension
Raido kit
Optical edge sensors kit
F-LinX Wifi
